In data science, you may end up with \(N\) vectors but only need to average \(M\) of them. A common scenario is when working with padding, where you may need to ignore vectors corresponding to padded indices. This operation should ideally be computationally fast and differentiable to support backpropagation (see [1]).

In this blog post, we’ll show a differentiable way to calculate the average of \(M\) out of \(N\) vectors using PyTorch. While we use PyTorch for all examples, the approach also works with other libraries that support linear algebra, like NumPy or TensorFlow.

To illustrate the concept, we’ll use 4 vectors of size 3. The method, however, generalizes to any number of vectors and dimensions.

Averaging

Let’s assume the vectors are arranged as columns in a matrix:

\[\begin{pmatrix} \vec{ v_0 } & \vec{ v_1 } & \vec{ v_2 } & \vec{ v_3 } \end{pmatrix}= \begin{pmatrix} v_{00} & v_{10} & v_{20} & v_{30} \\ v_{01} & v_{11} & v_{21} & v_{31} \\ v_{02} & v_{12} & v_{22} & v_{32} \\ \end{pmatrix}\]

In PyTorch, you can create a simple example of such a matrix via

vectors = torch.arange(0, 12).reshape(3, 4).float()

To compute the mean of all vectors

\[\begin{pmatrix} \frac{1}{4}(v_{00} + v_{10} + v_{20} + v_{30}) \\ \frac{1}{4}(v_{01} + v_{11} + v_{21} + v_{31}) \\ \frac{1}{4}(v_{02} + v_{12} + v_{22} + v_{32}) \end{pmatrix}\]

you can use

vectors_mean = torch.mean(input=vectors, dim=1, keepdim=True)

Suppose you only want to average vectors 0, 2, and 3, the expected result would be

\[\begin{pmatrix} \frac{1}{3}(v_{00} + v_{20} + v_{30}) \\ \frac{1}{3}(v_{01} + v_{21} + v_{31}) \\ \frac{1}{3}(v_{02} + v_{22} + v_{32}) \end{pmatrix} \tag{1}\]

To do this, define a mask that indicates which vectors to include. The mask has the same size as the number of vectors (4 in this case), with 1s indicating vectors to include and 0s for those to ignore.

\[\begin{pmatrix} 1 \\ 0 \\ 1 \\ 1 \end{pmatrix}\]

This is defined in PyTorch via

mask = torch.tensor([[1], [0], [1], [1]])

We sum the elements of the mask and divide each element by this sum, which norms the mask

\[\begin{pmatrix} \frac{1}{3} \\ 0 \\ \frac{1}{3} \\ \frac{1}{3} \end{pmatrix}\]

and in PyTorch

mask_sum = torch.sum(mask)
normed_mask = mask / mask_sum

Now, we perform a matrix-vector multiplication (see [2])

\[\begin{pmatrix} v_{00} & v_{10} & v_{20} & v_{30} \\ v_{01} & v_{11} & v_{21} & v_{31} \\ v_{02} & v_{12} & v_{22} & v_{32} \\ \end{pmatrix} \cdot \begin{pmatrix} \frac{1}{3} \\ 0 \\ \frac{1}{3} \\ \frac{1}{3} \end{pmatrix}\]

which can be computed in PyTorch as

vectors_0_2_3_mean = torch.matmul(vectors, normed_mask)

We retrieve the desired outcome (1).

To compute the mean over all vectors, like above, we use a mask of all ones:

\[\begin{pmatrix} 1 \\ 1 \\ 1 \\ 1 \end{pmatrix}\]

which is normed to

\[\begin{pmatrix} \frac{1}{4} \\ \frac{1}{4} \\ \frac{1}{4} \\ \frac{1}{4} \end{pmatrix}\]

torch.matmul, torch.sum and element-wise division are all computationally fast and differentiable operations, making them well-suited for use in neural networks with backpropagation.

How to Create Masks?

To create an alternating mask

\[\begin{pmatrix} 0 \\ 1 \\ 0 \\ 1 \end{pmatrix}\]

you can create a vector from index 0 to 3

\[\begin{pmatrix} 0 \\ 1 \\ 2 \\ 3 \end{pmatrix}\]

and apply an element-wise modulo operation. Since True is equivalent to 1 and False is equivalent to 0 (when converting from Boolean to Integer), we end up with the alternating mask

alternating_mask = (torch.arange(0, 4).reshape(4, 1) % 2).short()

For creating a mask that is 1 up to a certain index (here index 2, excluded)

\[\begin{pmatrix} 1 \\ 1 \\ 0 \\ 0 \end{pmatrix}\]

we also create a vector from index 0 to 3 and then apply an element-wise comparison against the target index; the result will be 1s for all positions less than the target and 0s otherwise.

mask_up_to_idx = (torch.arange(0, 4).reshape(4, 1) < 2).short()

Summary

In this blog post, we discussed an approach to calculate the average of \(M\) out of \(N\) vectors using masking and matrix multiplication. All operations are computationally fast and differentiable, making them well-suited for backpropagation in neural networks.
